Compact Single Genset Controller
The DSEG4500 Compact Single Genset Controller and DSEG4501 Compact Single Genset Controller with RS485 are part of the next-generation DSEG-Series platform, designed for versatility and performance. User-configurable for Remote Start (RS) or Automatic Mains (Utility) Failure (AMF) applications, they offer a robust feature set tailored to single genset operations.
Selected features include real-time monitoring of generator and load power, engine speed, oil pressure, coolant temperature, frequency, voltage, current, power, and fuel level. All critical data is displayed on a dedicated multi-line, text and icon high-resolution screen.
The DSEG4500 and DSEG4501 support both electronic J1939 (CAN) and non-electronic (alternator frequency sensing) engines, making them compatible with a wide range of fuel types including diesel, gas, and petrol. A generous number of flexible inputs, outputs, and protection features ensure adaptability for diverse applications.
Fully programmable via the DSE Configuration Suite software, the DSEG4500 and DSEG4501 deliver the renowned DSE easy setup experience, providing seamless integration and control.
OVERALL SIZE
142.6 mm x 118.6 mm x 48.5 mm / 5.61 ” x 4.66 ” x 1.91 ”
PANEL CUTOUT SIZE
118 mm x 92.0 mm / 4.65 ” x 3.62 ”
MAXIMUM PANEL THICKNESS
5 mm / 0.19 ”
PRODUCT VARIANTS
142.6 mm x 118.6 mm x 48.5 mm / 5.61 ” x 4.66 ” x 1.91 ”
PANEL CUTOUT SIZE
118 mm x 92.0 mm / 4.65 ” x 3.62 ”
MAXIMUM PANEL THICKNESS
5 mm / 0.19 ”
PRODUCT VARIANTS
G4500-01 - Compact Single Genset Controller
G4501-01 - Compact Single Genset Controller with RS485
DSEG4500-01
Sale price$716.00
Regular price$730.00
