Victron Orion-Tr Smart 12/24-10A DC-DC Charger

Ensure reliable, intelligent power management for your dual-battery setup with the Victron Orion-Tr Smart 12/24-10A Isolated DC-DC Charger. Designed specifically for 12V to 24V conversions, this adaptive 3-stage charger safely steps up your voltage while keeping your auxiliary battery fully charged and healthy.

Whether you're touring in a 4WD, setting up a camper van, or outfitting a marine vessel, the Orion-Tr Smart ensures optimal charging performance—even in vehicles equipped with smart alternators.

Key Features & Benefits

• Intelligent 12V to 24V Step-Up: Designed to take power from a 12V input system (starter battery/alternator) and efficiently step it up to properly charge a 24V auxiliary battery bank.
• Built-in Bluetooth Smart: Monitor real-time status, adjust output settings, and update software directly from your smartphone or tablet using the free VictronConnect app.
• Adaptive 3-Stage Charge Algorithm: Features Bulk, Absorption, and Float charging modes tailored for lead-acid and lithium batteries to maximize battery lifespan and performance.
• Smart Alternator & Engine Running Detection: Operates only when the engine is running to prevent over-discharging your starter battery—no complex CAN-bus integration or external sensors required.
• Galvanic Isolation: Electrically isolates input and output circuits to prevent ground-loop interference and enhance safety.
• Rugged & Heat-Resistant: Built with IP43 protection (when mounted with terminals down) and fully rated for high-ambient temperatures up to 40°C.
• Parallel Capability: Connect an unlimited number of units in parallel to scale up charging capacity as your system grows.

Specifications

• Input Voltage Range: 8–17V DC
• Output Voltage Range: 20–30V DC
• Nominal Output Current: 10A (240W)
• Efficiency: Up to 88%
• Operating Temperature: -20°C to +55°C (full output up to 40°C)
• Protection Class: IP43 (screw terminals facing downward)
• Dimensions: 130 x 186 x 80 mm
• Weight: 1.3 kg

Ideal Applications

• 4WDs & Overland Vehicles
• Caravans & Campervans
• Marine & Boats
• Off-Grid Solar & Dual-Battery Systems
